General Specifications
Regional Availability: Global
Platform: Desktop
Product Family: AMD Ryzen™ Processors
Product Line: AMD Ryzen™ 5 8000 G-Series Desktop Processors with Radeon™ Graphics
# of CPU Cores: 6
# of Threads: 12
Max. Boost Clock: Up to 5.0GHz
Base Clock: 4.3GHz
L2 Cache: 6MB
L3 Cache: 16MB
Default TDP: 65W
AMD Configurable TDP (cTDP): 45-65W
Processor Technology for CPU Cores: TSMC 4nm FinFET
Unlocked for Overclocking: Yes
CPU Socket: AM5
Max. Operating Temperature (Tjmax): 95°C
OS Support:
- Windows 11 - 64-Bit Edition
- Windows 10 - 64-Bit Edition
- RHEL x86 64-Bit
- Ubuntu x86 64-Bit
Connectivity
PCI Express® Version: PCIe® 4.0
System Memory Type: DDR5
Memory Channels: 2
Max Memory Speed:
- 2x1R: DDR5-5200
- 2x2R: DDR5-5200
- 4X1R: DDR5-3600
- 4x2R: DDR5-3600
Graphics Capabilities
Graphics Model: AMD Radeon™ 760M
Graphics Core Count: 8
Graphics Frequency: 2800 MHz
AI Engine Capabilities
Brand Name: AMD Ryzen™ AI
AMD Ryzen™ AI: Available
Performance: Up to 16 TOPS
Product IDs
Product ID Boxed: 100-100001237BOX
